The Taoglas PC60 and PC66 antennas offer a 617MHz to 6000MHz frequency range and support a wide range of 5G, 4G, and LTE cellular bands. Measuring 90 × 15 mm2, these antennas are intended for use where size constraints limit the use of a larger antenna.
Flexible, the PC60 and PC66 antennas include a peel-and-stick adhesive backing for simple installation, while small through-holes allow for an alternative mounting option where adhesive might not be appropriate. These antennas are suitable for compact IoT devices, remote monitoring and security cameras, point-of-sale terminals, and more.
The Olympian III antennas are high-performance combination permanent mount antennas that come in a rugged, IP67-rated enclosure. These antennas are offered in three variants. The MA182 offers 4G-5G MIMO connectivity, covers all worldwide LTE bands, and offers 3G/2G fallback when needed. The MA181 adds a GPS/GLONASS/Galileo antenna for positioning and location applications. The MA183 includes a wideband Wi-Fi antenna covering the Wi-Fi 6/7 frequencies, along with the legacy 2.4/5.8GHz Wi-Fi and Bluetooth frequencies.
The Olympian III series has been developed for smart metering, digital signage, transportation, and telematics.
The Taoglas HP2356.A Inception series is a low-profile GNSS patch antenna designed for optimum positional accuracy and positioning.
The antenna utilises an innovative ceramic patch within a patch antenna design with optimised gain for GPS L1/L2, Galileo, GLONASS and BeiDou bands and has a compact 35 × 35 mm2 footprint. At only 6 mm in height, the Inception antenna can be used in applications where typical stacked patch designs are too tall for the device.
The AA.185 Magma magnetic/adhesive mount antenna offers GPS, GLONASS, Galileo, and BeiDou L1/E1/B1 coverage in a robust ASA IP67-rated enclosure, allowing it to be used internally or externally in challenging environments. Measuring 35.7 mm square and 15 mm in height, the Magma antenna is well-suited for installations where durability and small size are crucial.
Both the Inception and Magma antennas are suitable for applications such as telematics, fleet management, asset trackers, precision agriculture, and autonomous vehicles and robotics.
